Nuvo Lighting S11655R1 48in 24W T5 LED Tube | CCT Selectable 3500K-6500K, Type B Ballast Bypass, Dimmable | Offices, Retail | Model S11655R1
Free returns on all eligible orders
You have 30 days to request a return. All open box or clearance items are final sale.
Description
A 48-inch, 24-watt T5 LED tube that replaces 54-watt fluorescents, ideal for offices, retail spaces, and warehouses where you want selectable color temperature and dimming.
This Nuvo Lighting LED T5 lamp is engineered for ballast bypass (Type B) installations, simplifying maintenance and boosting reliability. With four selectable color temperatures (3500K, 4000K, 5000K, 6500K), you can tailor the light from warm and inviting to crisp and energizing. The PET-coated frosted glass adds durability and safety, while delivering smooth, consistent illumination.
Best for
- Offices and cubicle areas needing bright, energy-efficient task lighting
- Retail stores where you want to adjust color temperature to flatter merchandise
- Warehouses and industrial spaces requiring reliable, long-lasting illumination
- Task areas like workshops or garages where dimming is useful
- Enclosed fixtures rated for damp locations
Not ideal for
- Spaces with existing ballasts that you prefer not to bypass—this is a Type B lamp only
- Outdoor applications exposed to rain or direct water—damp rated, not wet rated
- Areas needing a single fixed color temperature—this lamp is selectable at installation
How bright is it?
3200 lumens—about as bright as a 100-watt incandescent bulb or a 54-watt fluorescent. This is a solid output for task and general lighting in commercial or residential work spaces.
Light color and feel
Choose from 3500K (neutral white), 4000K (cool white), 5000K (daylight), or 6500K (cool daylight). The 80+ CRI renders colors reasonably accurately. Dimmable with compatible reverse-phase dimmers (120V only).
Sizing and fit
Measures 45.75 inches long, 0.62 inches wide, and 0.62 inches high. Fits standard T5 fixtures with G5 miniature bi-pin bases. Designed for 4-foot fixtures.
Specifications
- Fixture Finish: White
- Bulb Wattage: 24W
- Lamp Shape: T5
- ANSI Base: G5
- Lamp Base: Miniature Bi Pin
- Ballast Type: Type B
- Rated for Enclosed Fixture: True
- Dimmable: Yes-Dimmable
- Dimmable Text: Reverse Phase; 120V only
- Voltage: 120V-277V
- Lumens: 3200L
- Color Temperature: 3500K/4000K/5000K/6500K K
- Color Temperature: Neutral White to Daylight
- CRI: 80+
- Average Hours Rated: 50000
- CCT Selectable: True
- Operating Temperature: -4F to +113F (-20C to +45C)
- Incandescent Equivalent: 100WW
- Fluorescent Equivalent: 54WW
- 4-Foot Length
- 24W LED,54W Fluorescent Replacement
- 3200 Lumens
- 4 CCT Selectable: 3500K/4000K/5000K/6500K
- Type B: Ballast Bypass
- G5 Miniature Bi-Pin Base
- PET Coated Frosted Glass
- Dimmable with Compatible Dimmers
- Assembly Required: True
- Country of Manufacture: China
- Location Rating: Damp
- Safety Location: CULUS - Classified/CRUUS - Recognized Component
- Title 20: Exempt
- CEC: Lawful for sale in California
- Warranty: 5-Years
Frequently asked
Is the bulb included? Yes, this is the LED tube itself.
Is it dimmable, and what dimmer should I use? Yes, dimmable with compatible reverse-phase dimmers, but only at 120V.
Can I install this in a bathroom or outdoors? It is rated for damp locations, so it can be used in bathrooms or covered outdoor areas, but not in direct wet exposure.
What's the warranty? 5-year warranty.
Does this work with existing ballasts? No, this is a Type B lamp designed for ballast bypass. You must remove the ballast and wire directly to line voltage.
