A simple, sophisticated smart fan that works seamlessly in transitional, minimalist and other modern environments, Axis is perfectly sized for medium-sized kitchens, bedrooms and living rooms, and its wet-rated status and weather-resistant finish make it prime for outdoor use as well. Unleash the full potential of Axis with our Modern Forms app, which offers smart features like Adaptive Learning and Away Mode, and helps cut down on energy use by integrating with your smart thermostat.
- Part of the Axis Collection
- Finish: Matte Black
- Made of Aluminum
- Blade Made of ABS
- Style: Contemporary
- (1) 19.5W LED Bulb
- Bulb Color Temp: 2700 or 3000 or 3500
- Bulb Average Hours: 50000
- Bulb Lumens: 1600
- Bulb Beam Spread: Flood
- Bulb CRI: 90
- Voltage: 120
- Modern Forms Fans pair with the smart home tech you know and love, including Google Assistant, Amazon Alexa, Samsung Smart Things, Ecobee, Control4, and Josh AI. Coming Soon: Savant, Lutron Homeworks, and Nest.
- Free app download: Sync with our exclusive Modern Forms app to control fan speed, use smart features like breeze mode, adaptive learning, create groups, and reduce energy costs. New: Bluetooth compatible for improved range and an unlimited amount of fans can be controlled with remote or wall control within range.
- Battery operated Bluetooth remote control with wall cradle included (Part # F-RCBT-WT). Optional Bluetooth hardwired wall control sold separately (Part# F-WCBT-WT) and can be set-up as 3 or 4 way switches when you purchase more than one. Can be controlled through an Android or iOS wall mounted tablet with Wi-fi.
- Modern Forms Fans are made with incredibly efficient and completely silent DC motors and are up to 70% more efficient than traditional fans. Every fan is factory-balanced and sound tested to ensure each fan will never wobble, rattle or click.
- Bluetooth Remote Control with on/off, 6 speed, reverse, and dim to 1%, Android or iOS Device App Included
- Bluetooth Wall Control (Sold Separately) with on/off, 6 speed, reverse, and dim to 1%, Android or iOS Device App Included
- Sloped Ceiling Adaptable: Yes
- Maximum Slope: 32
- Dimmable: Yes
- Speeds: 6
- Reversible Motor: Yes
- CFM (High): 5695
- RPM (High): 167
- Airflow Efficiency: 163
- Number of Blades: 3
- Blade Span: 52
- Blade Pitch: 14
- Light Kit Included: Yes
- Remote Included: Yes
- Wall Control Included: No
- Length of Electrical Wire: 80"
- Downrod 1 Quantity: 1
- ADA: Yes
- Energy Star: Yes
- Title 24: Yes
- Safety Rating: ETL, cETL, UL, cUL, CSA CAN Listed
- For Use in Wet Locations
- Warranty Info: 5 years LED module, lifetime on the motor, and 1 year for all other parts.
Body Diameter: 7.25"
Motor Size: 125 X 20
Downrod 1 Size: 0.75"D X 6.0"H
Fan Width: 52"
Canopy Diameter: 6"
Blade Dimensions: 22.38"(L) x 12.25"(H)
Hanging Weight: 13.5 lbs.
Item Weight: 13.93 lbs.
