Kichler Arkwright Fan Motor Assembly | White Steel | Living Room & Bedroom | 7.5 x 15.25 in | Model 300146WH
Free returns on all eligible orders
You have 30 days to request a return. All open box or clearance items are final sale.
Description
A 7.5-inch fan motor assembly for Kichler Arkwright ceiling fans, in white finish, designed for use with separately sold blades and light kits.
The Arkwright fan motor assembly features a DC motor with 6-speed CoolTouch control and includes a remote. The white painted steel housing offers a clean, contemporary look. Blades and light kits are sold separately, allowing customization. This motor is Energy Star-certified when paired with specific blades (370027 or 370030).
Best for
- Customizing a Kichler Arkwright fan with your choice of blades and light kit
- Living rooms and bedrooms where a quiet, efficient DC motor is desired
- Spaces with sloped ceilings up to 30 degrees
Not ideal for
- Outdoor or damp locations - rated for dry locations only
- Users who want an all-in-one fan with included blades and light
- Small rooms under 10x10 ft where a 48-60 inch fan may be too large
How bright is it?
This is a fan motor assembly only; no light is included. Light kits are available separately.
Light color and feel
Not applicable.
Sizing and fit
The motor assembly measures 7.5 inches in width and 15.25 inches in height. It includes a 4-inch downrod and can accommodate ceilings up to 30-degree slope. The base/backplate is 5.85 inches in diameter. Compatible with Arkwright blades (sold separately) for a total blade span of 48-60 inches.
Specifications
- QTY Included: 1
- Finish: White
- Made of Steel
- Voltage: 120
- Electrical Req: 120V 60Hz AC
- Fan Blade Pitch: 13
- Fan Motor Type: DC
- Fan Motor Size: 125
- Fan Speeds: 6 Speed DC CoolTouch
- Downrod 1: 1.00 OD X 4.00 in
- Max Stem Tilt: 30°
- Remote: Yes
- Theme: Contemporary
- Part of the Arkwright Family/Collection
- Fan Warranty: LIMITED LIFETIME
- Safety Rating: ETL_Dry
- UL Listed: ETLR
- Overall Dimensions: 7.5 in (W) x 15.25 in (H)
- Base/Backplate Dimensions: 5.85 in
- Wire Length: 78 in
- Item Weight: 12.3 lbs
Frequently asked
Is the bulb included? No, this is a motor assembly only; no light kit or bulbs are included.
Is it dimmable, and what dimmer should I use? The fan speed is controlled via the included remote; it is not a dimmable light fixture.
Can I install this in a bathroom or outdoors? No, this fan motor is rated for dry locations only.
What's the warranty? Limited lifetime warranty.
What blades and light kits are compatible? Compatible with Arkwright blades (models 370025-370030) and light kits (380047, 380046), all sold separately.
