Hinkley Swell Illuminated 56in LED Smart Ceiling Fan | Modern Matte Black Steel and White Glass | Covered Patio & Indoor Living | 56 | Model 903856FBB-LDD
Free returns on all eligible orders
You have 30 days to request a return. All open box or clearance items are final sale.
Description
A 56-inch LED smart ceiling fan with integrated light, designed for modern covered patios and indoor living spaces, finished in matte black with white glass.
The Swell Illuminated fan combines a bold, dramatic silhouette with practical functionality. Its matte black steel body and white glass light kit create a contemporary statement, while the 6-speed DC motor and WiFi connectivity offer convenient control via the HIRO remote or Hinkley app. Damp-rated for covered outdoor use, it brings style and comfort to any room.
Best for
- Covered patios, porches, and sunrooms where damp-rated fixtures are required
- Living rooms and great rooms with ceilings 8 ft or higher, providing both air circulation and ambient light
- Bedrooms and home offices needing quiet, energy-efficient cooling with adjustable speed
- Spaces where smart home integration is desired, with WiFi and app control
Not ideal for
- Uncovered outdoor areas exposed to direct rain (damp-rated only, not wet-rated)
- Rooms with ceilings under 7 ft (minimum installation height is 7 ft from floor)
- Spaces requiring a traditional pull-chain fan (control is via remote or app only)
How bright is it?
The integrated LED produces 1320 lumens — comparable to a 75W incandescent bulb, providing ample ambient light for most rooms. It is dimmable with a CL-type dimmer (SSL7A) for adjustable brightness.
Light color and feel
3000K warm white light creates a cozy, inviting atmosphere similar to traditional incandescent bulbs. With a CRI of 90, colors appear vibrant and accurate, ideal for living areas and entertaining spaces.
Sizing and fit
The fan has a 56-inch blade sweep and a 10-degree blade pitch, suitable for rooms up to 400 sq ft. Overall dimensions are 56 x 56 x 15 inches, with a ceiling-to-blade height of 10.75 inches. A 6-inch down rod is included; other lengths are available separately. The fan can be installed on sloped ceilings up to 20 degrees.
Specifications
- Part of the Swell Illuminated Collection
- Finish: Matte Black
- Made of Steel
- Blade Finish: Matte Black
- Blade Made of Wood
- Glass: White
- Style: Modern
- (LED) 16.00W LED Bulbs
- Bulbs Included
- Bulb Color Temp: 3000.0
- Bulb Average Hours: 50000.0000
- Bulb Lumens: 1320
- Bulb CRI: 90
- Voltage: 120v
- Light Source: Integrated LED
- This item includes a light kit cover | Fan Control included, HIRO Control - 6 Speed Reversing | Suitable for use in damp locations as defined by NEC and CEC. Meets United States UL Underwriters Laboratories & CSA Canadian Standards Association Product Safety Standards. | For more information on how to control your ceiling fan via the Hinkley Home Automation App, click here. | Bold silhouette with dramatic details creates a modern statement | WiFi compatible with included fan control | This item includes a 6" down rod. Other various lengths of down rods are available and sold separately to customize the installation height. | This item may be hung on a sloped ceiling | Blades, controls, switches, capacitors and hardware carry a 1-year warranty | This product uses recyclable or limited packaging materials to help reduce waste. | Motor carries a lifetime warranty | Fans should be installed at a minimum of 7 feet from the floor
- Eco-Friendly Packaging
- Fan Control included, 6 Spd HIRO:R
- FAN: 6" Rod Included, FAN: 7ft from floor, Install Sloped Ceiling
- CALIFORNIA PROP 65: WARNING: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Dimmable: Yes, CL Type Dimmer (SSL7A)
- Sloped Ceiling Adaptable: Yes
- Slope Degree: 20
- Ceiling to Blade Height: 10.75
- Motor Type: DC
- Fan Speed: 6 Speed
- Reversing Control: Yes
- Control Type: HIRO Control - 6 Speed Reversing
- Number of Blades: 3
- Blades Included: Yes
- Blade Sweep: 56
- Blade Pitch: 10
- Light Kit Included: Yes
- Certification Type: UL
- Safety Rating: C-US Rated Listed
- For Use in Damp Locations
- Overall Dimensions: 56.0"(L) x 56.0"(W) x 15.0"(H)
- Canopy Depth: 2.2500"
- Canopy Dimensions: 6" Dia.
- Item Weight: 28.6 lbs.
Frequently asked
Is the bulb included? Yes, the integrated LED is included and rated for 50,000 hours.
Is it dimmable, and what dimmer should I use? Yes, it is dimmable with a CL-type dimmer (SSL7A).
Can I install this in a bathroom or outdoors? It is rated for damp locations, so it can be used in covered outdoor areas and bathrooms with no direct water exposure, but not in wet locations.
What's the warranty? The motor carries a lifetime warranty; blades, controls, switches, capacitors, and hardware carry a 1-year warranty.
Does it work with sloped ceilings? Yes, it is adaptable for sloped ceilings up to 20 degrees.
