WAC Lighting Field Cut End-Connector/Sealant For LED 24Vdc Strip, Black
by WAC Lighting
$24.99
SKU WAT24-WE-EX2-006-BK
Designed for indoor and outdoor use, this durable and professional grade 24V strip light delivers superior color consistency and brightness throughout the strip. Up to 80ft max run on the 1.2w/ft strips and up to 40ft on the 2.4W/ft strips on a single power supply. IP65 outdoor wet location rating with a silicon coating that protects against the elements in outdoor environments while offering 3 color temperature choices of 2700k(Warm)-3000K(Warm White)-4000K(Cool White) to illuminate hardscaping, landscaping and architectural features. InvisiLED outdoor strips are field cuttable at the end of a run for maximum versatility and are available in 1ft, 5ft, 10ft, 20ft, 40ft, or 80ft rolls (80ft only available in 1.2w/ft option).
- Finish: Black
- Made of Silicon
- Style: Functional
- Voltage: 24
- Lead Wire, Small Silicon Tube
- Field cut connector can be soldered onto the end of a cut to reuse the remaining strip or jump to another strip with power continuity. Includes a silicone sealant to create a water-tight seal. Fully enclosed IP65 outdoor wet location rated with a unique silicon coating that protects against the elements in outdoor environments. Power supply (Sold Separately Part # PS-24DC-U96R-WE) is IP 67 rated for outdoor installation as well.
- InvisiLED Outdoor Strip Lights are available in 1.2W/ft and 2.4W/ft power options, 2700K(Warm)-3000K(Warm White)-4000K(Cool White) color temperature options, and 1ft, 5ft, 10ft, 20ft, or 40ft length options. Up to 100ft max run on the 1.2w/ft strips and up to 40ft on the 2.4W/ft strips on a single power supply.
- Each strip includes a 6in lead with a male-to-female connector on each side to create a water-tight connection. InvisiLED Outdoor Strip Lights can be cut in the field every 4in and re-used by applying a field cut connector kit sold separately (Part # T24-WE-EX2-006-BK).
- Smooth and continuous dimming with an electronic low voltage (ELV) or TRIAC dimmer. Dimmers should be installed on the primary side of the transformer. Driver input voltage: 120V-220V-277V AC, Driver output voltage: 24V DC. Driver is available in a 96W max load.
- High Powered LED: Color Temperature: 2700K, 3000K, or 4000K, 90+ CRI, Rated Hours: 80,000, Voltage: 24V, Lumen Options: 100+ lm/ft, or 200+ lm/ft.
- Standards: UL & cUL Listed for Wet Locations. Power supply is IP67 rated, InvisiLED Outdoor Strip Lights are IP65 rated. CEC Title 24 & ADA Compliant.
- ADA: Yes
- Interior/Exterior: Interior/Exterior
- Hardwired/Portable: Plugin
- Length of Electrical Wire: 8"
- Safety Rating: UL/CUL/IP65 Listed
- For Use in Wet Locations
- Warranty Info: 5 Years Functional, 2 Years Finish
Overall Dimensions: 8"(L) x 0.57"(W) x 0.38"(H)
Item Weight: 0.08 lbs.
